Kingkong Combo Meter no longer available

Trimax Meters ended production in 2016. Meters under the Trimax name are no longer available. Sathero Meters are the most technically advanced hand held meters.

HIGHLIGHTS

  • DVB-S2 & DVB-T2 & DVB-C
  • GPS for Location
  • COMPASS for Azimuth
  • G-SENSOR for Elevation
  • ROTARY CONTROL
  • 7 INCH DISPLAY
  • AV IN/OUT
  • BER, S/N, MER, Power, FEC Measurement
  • HDMI
  • RJ45
  • CAM
  • Card Reader
  • USB

FEATURES

  • Full Measurement for DVB-S2 & DVB-T2 & DVB-C
  • Asynchronous Serial Interface Supported
  • Annex A/B/C Supported by DVB-C tuner
  • Real-time and Multi-Analyzing Spectrum
  • Constellation Chart
  • GPS/LCN
  • BER, S/N, MER, Power, FEC Measurement
  • Auto Search, Blind Search, NIT Search., Manual Search
  • Satellite Name & Degree Auto Detective & Display
  • Auto DiSEqC1.0/DiSEqC1.1/DiSEqC1.2, USALS
  • MDU & Unicable
  • Local satellites list showing automatically
  • Transport Stream Recording Supported
  • H.264 HDTV
  • AV-OUT for External Display TV
  • AV-IN Function for STB, Camera etc.
  • Easy upgrading by Ethernet & USB & RS232 Port
  • Satellite List Editable by Editor via PC
  • Data Backup
  • Conax/CA Embedded
  • Common Interface Supported
  • 13V/18V, 22K supported
  • Dish Antenna Angle Calculator
  • Multi-Language OSD: English, German, French, Spanish, Italian etc.
  • Global, Local Satellite list
  • Build-in GPS receiver
  • 7 Inch High Definition TFT LCD Screen
  • LED(Red/Green) & Audio Indication for Signal Lock

SPECIFICATIONS

Tuner
DVB-S2:
Demodulator Mode QPSK,8PSK,16APSK
Input Frequency 950~2150MHz
Input Impedance 75Ω, Input Level 65 ~ -25dBm
Symbol Rate 2 to 45 Mbauds
Code Rate 1/2,2/3,3/4,5/6,7/8
DVB-T2
Demodulator Mode QPSK,16QAM,64QAM,256QAM
Frequency Range 110MHz-862MHZ
Channel Bandwidth 6MHZ, 7MHZ, 8MHZ
DVB-C
Demodulator Mode 16QAM,32QAM,64QAM,--128QAM,256QAM
Frequency Range 110MHz-862MHz
Symbol Rate 1000 to 7000 kbauds
Power Range
DVB-S 45 dBµV to 100 dBµV
DVB-T 45 dBµV to 110 dBµV
DVB-C 44 dBµV to 114 dBµV
Video
Video Decoding ISO/IEC 11172-2 MPEG1, ISO/IEC 13818-2 MPEG2 MP@HL
ISO/IEC 14496, MPEG4 Compliant Support SP@l3 to ASP@L5
ISO/IEC 14496-10 AVC high, Profile@level 4.1 Main profile@level 4.1
Video Output CVBS (video format@576i or 480i)
HDMI 1.3 (video format default @ Auto, Support HDCP
Video Resolution 1080p/i 720p/i 576p/i 480p/i
Aspect Ratio Support 4:3 16:9
Audio
Audio Decoding MPEG1 Layer1/2, MPEGII LayerII
Audio Mode Mono/Stereo/Left/Right
Power
DC Input Range 15V 1.5A
Power Consumption 22 W (Max)
Operating Environmental Conditions
Temperature Range -20°C - 60°C
Max. Relative Humidity 45% - 75% RH
Mechanical Features
Size (WxDxH) in mm 260x145x59
Weight 0.8kg
