Trimax Meters ended production in 2016. Meters under the Trimax name are no longer available. Sathero Meters are the most technically advanced hand held meters.
HIGHLIGHTS
FEATURES
SPECIFICATIONS
| System Capabilities | |
| DVB-S/S2 Compliant | Yes |
| LNB/Tuner Input For DVB-S/S2 | |
| Connector | F type, male |
| Frequency Range | 950MHz-2150MHz |
| Signal Level | -65dBm~-25dBm |
| LNB Supply | 13/18V,max500mA |
| LNB Switch Control | 22KHz |
| Impedance | 75Ω |
| Demodulator for DVB-S/S2 | |
| Front End | QPSK(DVB-S)8PSK(DVB-S2) |
| Symbol Rate | 2Mbps~45Mbps(DVB-S) |
| 2Mbps~30Mbps(DVB-S2) | |
| SCPC and MCPC Capable | Yes |
| Spectral Inversion | Auto conversion |
| System Resource | |
| Processor | 32bit processor |
| SDRAM | 16Mbytes |
| FLASH | 2Mbyte |
| Video Decoder | |
| MPEG 2 | Main Proflie@Main Level |
| Data Rate | up to 15M bits/s |
| Resolution | 720*576,720*480 |
| Video Format | PAL/NTSC/SECAM |
| MPEG Audio | |
| MPEG 1 layer 1&2 | YES |
| Type | Mono |
| Sampling Rates | 32,44.1 and 48KHz |
| Port | |
| Connector | USB,RS232, Ethernet, AV-OUT,DC |
| Power Supply | |
| Li-ioN Battery | 2000 mAH |
| Supply Voltage | 13.3Volt |
| charger | 90-240V |
| Panel Connectors | |
| Digital Tuner Input | F type, Male |
| Physical Specification | |
| Size (WxDxH) in mm | 139x99x37 |
| Weight(Net) | 0.44KG |
| Monitor | |
| Display Screen | 3 Inch TFT |
| Signal Strength Display | Yes |
